| Sensor | Thermocouple:J/K/T/E/S/N/B/R |
| Accuracy | ±0.2% ±2 Digits (Excluding Thermocouple) |
| Range | -200℃~1800℃ (variation depend on sensor) |
| Resolution | 0.01℃ |
| Channels | 200 channels;(Customizable number of channels, incremented/decremented by 10 channels each time) |
| Speed | fast: 500ms/channel, slow: 1s/channel |
| Correction | Error correction for each channel |
| Comparator | high & low beep function for each channel |
| Interface | RS232C, U-disc, Type-c，LAN；It can also be optionally equipped with an RS485 interface |
| Software | ATS45 data acquisition software |
| Cold Junction | Accuracy: 0.5℃ |
| Other Functions | TFT-LCD True color display, broken thermocouple check function |
| Power Supply | V: 100VAC～240VAC Fre：47.5-52.5Hz Power：10VA |
| Dimension & Weight | 294x130x316mm weight：3kg |
| Accessories | Thermocouple, 2 meters long, 10 pieces per set (including the corresponding number of thermocouples for the channel count).TYPE-C Communication Cable;ATS45 Data Acquisition Software |
